Description:
Item Name: Brushed ESC
Working Voltage: 3-6V
Current: 6A x 2
Boost Power: 5V 600ma
Dimension: 30x16mm
Weight: 5g
Features:
- BEC with 5V 600mA boost, support 3.7/4.3g servo.
- One-Way 6A,Two-way 6Ax2, suitable for 1020/8520/720/N30/N20 Coreless Motor
- Support two motors (such as the 8520) connected in parallel on the ESC.
- Remote control signal pwm (1000-2300us) run automatically adapts.
- Low throttle (less than 1150us) unlocks to prevent high throttle motor immediately movement .
- Support failsafe.
- With start prompt sound.
Receive / Servo Power Supply Instructions:
When 1S high current discharge, the voltage drop is very large, the lithium battery voltage may drop below 3V, at this time most receivers will be powered off (the actual lithium battery capacity may still be more than 50%, can be restored to 3.8V above when not discharged). Therefore, this ESC BEC adopts a boost design. In actual test, when two 4.3g servos (current about 500ma) are used, the lithium battery discharge voltage is reduced to 3V (or even 2.8V),it still can work properly.
Package Included:
1 x ESC
