Specification:
FPV Transmitter:
Frequency: 5.8G
Channel: 48CH
Working current: 130mA(25mW)/230mA(200mW)/280mA(600mW)/12V
Transmit power: 25/200/600mW/OFF Switchable
Power supply: DC6-24v
Antenna impedance: 50ohm
Antenna Connector: RP-SMA male
Transmit distance: 25mW/200m 200mW/1.5km 600mW/5km
Size: 32.5*22.6*7.25mm
Weight: 8g
FPV Camera:
Image Sensor: 1/2.7'' CCD
Resolution: 700TVL
Lens: 2.5mm
Format: NTSC/PAL(Free switch)
Signal to noice ratio: ï¼60Db(AGC OFF)
Aspect ratio: 16/9
Electronic shutter PAL: 1/50-100,NTSC: 1/60-100
Automatic gain control: Yes
Backlight compensation: Yes
Intensity of illumination: 0.001 LUX/1.2F
Power: DC 5V-24V
Weight: 22.3g
Size: 25*25mm
Color: Black/Red
Package included:
2 x 2.5mm 700TVL CCD Dual FPV Camera
1 x EWRF 5.8G 48CH 25/200/600mW Switchable FPV Transmitter
1 x Switch
