Description:
Item Name: Battery Testing Instruments Digital Display
Size: 27*14*8mm
Type: Suitable for 3 Cell Lipo 12V, 9 Cell Ni-MH
Features:
1. Wider range of usage, which can be used in lithium batteries, lead-acid batteries, electric car batteries, nickel-metal hydride batteries.
2. Electric equipment power display.
3. Static current consumption is 0, energy saving.
Instructions:
1. Binding the wire according to the polarity of the battery.
Instructions:
1. Binding the wire according to the polarity of the battery.
2. Hold down the Meaeurement Button, the digital power display tube will display the real battery power between 10% and 100% accurately .
3. Loose the button, it will get into the power-saving mode, and there will be no power consumption.
Lithium display power parameters (Calculation formula: e.g. 3 cells lipo: 3 * 3.3 = 9.9V) :
Battery voltage> N x 3.1V, display 10%
Battery voltage> N x 3.2V, display 20%
Battery voltage> N x 3.3V, display 30%
Battery voltage> N x 3.4V, display 40%
Battery voltage> N x 3.5V, display 50%
Battery voltage> N x 3.6V, display 60%
Battery voltage> N x 3.7V, display 70%
Battery voltage> N x 3.8V, display 80%
Battery voltage> N x 3.9V, display 90%
Battery voltage> N x 4.0V, display 100%
Package Included:
2X Lipo Battery Testing Instruments And Ni-MH Battery Digital Display
Package Included:
2X Lipo Battery Testing Instruments And Ni-MH Battery Digital Display
