4X JX PDI-6221MG 20KG Large Torque Digital Standard Servo 360 Degree CW
Description:
Brand: JX
Item: PDI-6221MG 20KG Large Torque Digital Standard Servo
Degree: 360°clockwise
Dead band: 2μs
Working frequence: 500μs /2500hz, pulse width in 1500us shutoff
Angle Range: 360°continuous rotate
Operating Speed : DC4.8V-6.6v
Stall Torque (4.8V): 53R/M
Stall Torque (6V): 65R/M
Dimensions: 40.5X20.2X38mm /1.59 X0.80X49 in
Weight: 62 g (2.18oz)
Connector Wire Length: JR 265 mm (10.43in)
Bearing: 2BB
PDI-6221MG+360: 1500us-500us is reverse direction, 1500us-2500us is forward direction.
Features:
- High performance digital standard servo
- High-precision aluminium gears with hard anodizing
- CNC aluminium middle Shel
- Dual ball bearings
Package Included:
4 x PDI-6221MG 20KG Large Torque Digital Standard Servo 360 Degree CW
