5.8G 700TVL 20~200mW 40CH NTSC+PAL Mini Transmitter Camera Combo
Specification:
Size: 37*18*14mm
Weight: 7.5 g
700TVL Philips FPV Camera
Lens wide angle: 170 degrees
Video format: NTSC + PAL composite video signal
Resolution: 1280 * 960
Focal length: F = 1.8mm
Working current: 80mA
Operating voltage: 3.5 ~ 5.0V
Minimum illumination: 0.5lux
4.8G 40 frequency 200 mW FPV diagram transmission
Video system: NTSC + PAL composite video signal
Output impedance: 50Ω
Output signal strength: 13 ± 1dbm
Output power: 20 ~ 200mw
Wireless frequency: 40 channel frequency
Operating voltage: 3.5 ~ 5.0V
Operating current: up to 460mA
Sound Carrier: Microphone
Four-leaf circular polar antenna
Size: 12 * 30mm
Polarization: RHCP
Warm Tips: 200mW power, due to increased heat products, please provide adequate cooling, to avoid prolonged static state.
Otherwise the product will enter the self-protection state due to overheating, cut off the output model. After this phenomenon,
please cut off the product power, until the product is fully cooled automatically restored.
Features:
1 x Transmitter camera combo
Warm Tips: 200mW power, due to increased heat products, please provide adequate cooling, to avoid prolonged static state.
Otherwise the product will enter the self-protection state due to overheating, cut off the output model. After this phenomenon,
please cut off the product power, until the product is fully cooled automatically restored.
Features:
Small size, light weight
Can be installed in the RC aircraft, cars, boats (need to do a good job of waterproofing) and so on
Module 5V voltage, can be obtained from the receiver idle channel power supply
or connected to the BEC corresponding 5V power supply port, with the bottom of the 3M mushroom paste, flexible deployment
Package included:or connected to the BEC corresponding 5V power supply port, with the bottom of the 3M mushroom paste, flexible deployment
1 x Transmitter camera combo
