700TVL 3.6mm Lens 1/3" CMOS PAL Mini FPV CCTV Camera Family Monitor
Specifications:
Model:555445
Material:Metal+Galss
Lens: 3.6mm Glass lensVoltage: DC12V+-5%Working current: 70MA
Size: 36 x 36 x 10mm
Sensor: 1/3" CMOS Sensor
Resolution: 700TVL
Min lumen: 0.01LUX/F1.2
SNR: <=48dB
Video out put: 1.0Vp-p/75ohm
Elsctronic Shutter: 1- 1/1000second
Working temperature: -20°C-60°C
Features:
* Made of high quality metal shell,strong hardness,not easy broken.
* 180°C rotating bracket, convenient for use, also can be installed on the wall.
* 700TVL camera,high resolution,3.6mm lens,wide monitoring range.
* Multi-function,not only can be used for aerial, also can do family monitoring.
Package Include:
1 x 1/3" 700TVL 3.6mm Mini CMOS Camera
1 x Cable
Cable Tip:
Red line:Connect positive
Yellow line:Connect cathode
Black line:video signal
