Aokfly BS1408 1408 2500KV 5-6S / 3600KV 3-4S Brushless Motor 1.5mm Shaft for RC Drone
Notice: The Propeller is NOT Included.
Specification:
Brand Name: Aokfly
Model: BS1408
Item Name: 1408 2500KV 5-6S / 3600KV 3-4S Brushless Motor
KV: 2500KV / 3600KV ( Optional)
Quantity: 1 PC
Input Voltage: 5-6S Lipo@2500KV ; 3-4S@3600KV
Confi-guration: 9N12P
No-Load Current: 0.46A@2500KV; 1.23A@3600KV
Wire: 22AWG, 100mm Length
Internal Resistance: 168mΩ@2500KV; 91mΩ@3600KV
Max. Power: 387.8W@2500KV; 339.5W@3600KV
Max. Current: 16.2A@2500KV; 21.2A@3600KV
Shaft Diameter: 1.5mm
Dimension: 19.3x18.3mm
Weight:16.7g
Application: for 120-1500mm FPV Racing Drone
Pacakge Incldued:
1x BS1408 Motor
1x 1.2E C-clip
2x M2*7 Screws
4x M2*5 Screws
