AuroraRC C3 Flytower Omnibus F3 Flight Controller AIO BL_S 35A ESC 48CH 25-600mW VTX for RC Drone - 78.00 €

AuroraRC C3 Flytower Omnibus F3 Flight Controller AIO BL_S 35A ESC 48CH 25-600mW VTX for RC Drone
Seller: Banggood,
Ship from: CN Warehouse, Usually dispatched in 1-3 work days.

FREE SHIPPING: 10-35 days. (DHL faster please check price/quantity first)
Free shipping aviable, Registered postage from 25 €


AuroraRC C3 Flytower Omnibus F3 OSD Flight Controller AIO BL_S 35A ESC 48CH 25-600mW VTX for RC Drone




















Specification:
Brand name: AuroraRC
Item name: C3 flytower
Size: 45*45*20mm
Mounting hole: 30.5mm
Weight: 32g

Omnibus F3 flight controller:
CPU: STM32F303CCT6
Sensor: MPU6000 three-axis accelerometer / three-axis gyroscope (SPI connection)
Power input: 2-6S lipo
BEC: 5V/3A
Receiver: support PPM, SBUS, DSM2/DSMX, IBUS...
Supports programmable LED_Strip (turns off Transponder before use)
Support BLheli suite ESC programming
Support the newest firmware: betaflight_3.2.0
With the newest DSHOT1200, PROSHOT ESC protocol
Built-in OSD, Cleanflight/ Betaflight online tuning
Built-in voltage detection, alarm
Built-in buzzer
With LC filter
Reserved IIC interface

DSM, SBUS receiver input, please configure RX3 as input interface.

BLHeli_S 35A ESC:
Input voltage: 2-6S lipo
Con. current: 35A
Size: 36*36mm
Weight: 12.2g
BEC: NO
Support Dshot150, Dshot300, Dshot600
Support Oneshot /Multishot /Dshot BLHELI_S firmware

5.8G 48CH VTX:
Input voltage: DC 7-27V
Input current: 16.4V(4s), 600mW=360 MA±10MA
Output voltage: DC 5V 1A
Output power: 25/100/200/400/600mW switchable
Channel: 48CH
Frequency switch: manual button/OSD (simultaneous support)
Connector: MMCX (with sma extension cable)
Size: 36x36x9mm
Mounting hole: 30.5x30.5mm, M3
Weight: ≤6.4g (without antenna and connector)

Package included:
1x Omnibus F3 flight controller
1x BLHeli_S 35A ESC
1x 48CH 25-600mW VTX
1x X60 power cable
1x 8P cable
2x 3P cable
1x VTX connecting cable
1x antenna conversion cable
12x nylon screws
4x nylon screw nuts
