Description:
CHEERSON CX - 23 CHEER brushless RC quadcopter makes every moment of your flight cheerful.
Equipped with GPS, it offers you a more reassuring flight, since it will return automatically in case of loss of signal. More interestingly, the flight radius can be set up to make the UAV circle around a certain object and get 360-degree panning shots effortlessly. Thanks to the powerful D1306 3300KV brushless motors, the drone can reach the speed of 15m/s ( in Normal Mode ) and 10m/s ( in GPS Mode ), giving you the sensation you are looking forward to.
Moreover, 5.8G FPV monitor, which features the OSD and channel auto search, presents the clear and fluent aerial view to you, putting your eyes in the air.
Main Features:
â GPS enables Altitude Hold, Position Hold, Automatic Return and high hover accuracy of + / - 0.2m
â Point of Interest allows you to set up the radius and choose the object that you want the drone to fly around
â 2MP camera with adjustable angle for taking 1920 x 1080 stills and 1280 x 720 HD videos
â 5.8G FPV system offers you the aerial view on the 4.3 inch 1280 x 720 monitor within the range of 500m
â Two-way transmitter indicates height, orientation, speed ( horizontal and vertical ), battery level of the drone in real time
â Convenient plug-in 7.4V 1200mAh 20C LiPo battery provides up to 14 minutes long flight time
Specifications:
Size: 16.50 x 16.50 x 4.50cm ( excluding propellers and landing skids )
Brushless motor: D1306 3300KV
Propeller: 4045 ( diameter: 120mm )
Transmitter
Frequency: 2400 - 2483MHz
LCD display: yes
Battery: 5V 2000mAh ( built-in )
Charge time: about 150 minutes
Operation time: about 80 minutes
Charging current: 1A ( 5V )
FPV Monitor
Screen size: 4.3 inches
Resolution: 1280 x 720
Power supply: built-in rechargeable battery
Operation time: about 80 minutes
Charge time: about 90 minutes
Frequency Table
Band A 5658 5695 5732 5769 5806 5843 5880 5917
Band B 5740 5760 5780 5800 5820 5840 5860 5880
Band C 5865 5845 5825 5805 5785 5765 5745 5725
Band D 5705 5685 5665 5645 5885 5905 5925 5945
Specification
General |
Brand: Cheerson
Type: Outdoor,Quadcopter Model: CX - 23 Features: 5.8G FPV,Brushless Version,Camera,Radio Control Motor Type: Brushless Motor Functions: Emergency Landing,Fail-safe,Forward/backward,GPS Altitude Hold,Hover,Low-voltage Protection,One Key Automatic Return,One Key Landing,One Key Taking Off,Point of Interest,Sideward flight,Turn left/right,Up/down,With light Size: Medium Satellite System: GPS Max Speed: 10m/s ( GPS Mode ), 15m/s ( in Normal Mode ) Max Ascent Speed: 5m/s Max Descent Speed: 5m/s Hover Accuracy: +/- 0.2m Built-in Gyro: 6 Axis Gyro Material: ABS/PS,Electronic Components Kit Types: RTF Level: Beginner Level Age: Above 14 years old |
|---|---|
Connectivity |
Remote Control: 2.4GHz Wireless Remote Control
Channel: 6-Channels Radio Mode: Mode 2 (Left-hand Throttle) Detailed Control Distance: About 500m Compatible with Additional Gimbal: No FPV Distance: About 500m FPV Screen Size: 4.3 inches FPV Screen Resolution: 1280 x 720 Transmitter Power: Built-in rechargeable battery Model Power: Built-in rechargeable battery |
Battery |
Battery: 7.4V 1200mAh 20C 8.9Wh LiPo
Flying Time: about 14mins Charging Time.: about 90mins Battery Size: 7.9 x 2.8 x 2.4cm ( excluding protrusion part ) Battery Weight: 66g |
Camera |
Camera Pixels: 2MP, 1920 x 1080 ( JPG )
Video Resolution: 1280 x 720 ( AVI ) External Memory: TF card up to 8GB |
Dimension and Weight |
Product weight: 0.2210 kg
Package weight: 1.7050 kg Product size (L x W x H): 16.50 x 16.50 x 4.50 cm / 6.5 x 6.5 x 1.77 inches Package size (L x W x H): 25.50 x 25.50 x 13.00 cm / 10.04 x 10.04 x 5.12 inches |
Package Contents |
Package Contents: 1 x Quadcopter ( Battery Included ), 1 x Transmitter ( Battery Included ), 1 x FPV Monitor ( Battery Included ), 1 x Charger, 2 x Spare Propeller, 2 x Landing Skid, 2 x Screw, 1 x Screwdriver Set, 1 x Wrench, 2 x Antenna for Transmitter, 1 x 8GB Micro SD Card, 1 x Card Reader, 2 x Charging Cable, 1 x English Manual |
