Specification:
Model: Cpro X
Item Name: 155mm Wheelbase 3 Inch Frame Kit
Wheelbase: 155mm
Structure: HX type split
Material: 3K Carbon Fiber
Bottom Plate Thickness: 3mm
Upper Plate Thickness: 1.5mm
Internal Standoff Height: about 30mm
Camera installation width: 22mm
Weight: 76g (including a full set of 3D prints)
Recommend Parts:
Flight Controller: 20x20mm / 30.5x30.5mm F4/F7 Flight Controller
Brushless Motor: 13XX / 14XX Series Motor ( 9x12mm Mounting Hole)
Brushless ESC: 15-35A ESC
Propeller: Max. 3 Inch Propeller
Camera: 22mm Width
Lipo Battery: 3-4S 650-850mAh Lipo
The following Parts are Compatible: ( Not Included)
FC & ESC Stack: 20x20mm MAMBA F405 MINI DJI F35 3-6S Flight Controller FPV Combo
Brushless Motor: LDARC XT1304 1304 4100KV 3-4S Brushless Motor
Lipo Battery: TATTU 14.8V 850mAh 75C 4S XT30U-F Plug Lipo Battery
Package Included:
1x Cpro X 155mm Frame Kit
