CYS-BLS5120 20KG Large Torque Digital Standard Brushless Motor Servo For RC Model - 54.00 €

CYS-BLS5120 20KG Large Torque Digital Standard Brushless Motor Servo For RC Model
Seller: Banggood,
Ship from: CN Warehouse, Usually dispatched in 1-3 work days.

FREE SHIPPING: 10-35 days. (DHL faster please check price/quantity first)
Free shipping aviable, Registered postage from 25 €

CYS-BLS5120 20KG Large Torque Digital Standard Brushless Motor Servo For RC Model



Description:

Item No.CYS-S5120
TypeDigital
Weight64g
Size40.3*20.3*39.2mm
Control System(+)Pulse Width Control 1500usec Neutral
Operating Voltage6.0~7.4Volts
Operating Temperature Range(-)10 to +50 degree C
Operating Speed (6.0V)0.11sec/60° at no load
Operating Speed (7.4V)0.09sec/60° at no load
Stall Torque (6.0V)17kg.cm
Stall Torque (7.4V)20kg.cm
Operating Angle45deg.one side pulse traveling 500 usec
360 ModifiableNo
DirectionAnticlockwise/Pulse Traveling 1000~2000usec
Current Drain 6.0V)5mA/idle and 100mA no load operating
Current Drain (7.4V)5mA/idle and 120mA no load operating
Stall Current3.4A/4.2A
Dead Band Width2usec
Motor TypeBrushless motor
Bearing TypeDual Ball Bearing
Horn gear spline25T
Gear TypeTitanium
Connector Wire Length300mm
Brown/Black = Negative
Wire info Red = Positive
Orange/White = Signal

Important Notes:

-Refer to the figure when installing the servo accessories.
-For engine powered airplanes and boats, rubber must be used to reduce vibration.
-Please choose correct model for your application.
-Torque over-loaded will damage the servo's mechanism-.
- Keep the servo clean and away from dust, corrosive gas and humid air.

Package Included:
1 x CYS-BLS5120 20KG Brushless Motor Servo
