Description:
Brand: DEKO
Product: Digital Servo
Type: A: D1102 B: HV1295
A: D1102 Swashplate/Head-locking Digital Servo
Voltage: 4.8-7.4V
Torque: 2.6kg.cm(4.8V), 3.2kg.cm(6.0V), 3.9kg.cm(7.4V)
Speed: 0.088Sec/60°, 0.07Sec/60°, 0.058Sec/60°
Working Frequency: 1520/333hz
Spline: 25T
Motor: Coreless Motor
Weight: about 18g
Size: 28*12*23mm
Application: For ALIGN 450/450L/470L, ALZRC 450/480/465/X360/380/420,GUAI X3 RC Helicopter
B: HV1295 Swashplate Digital Servo
Voltage: 6.0-8.4V
Torque: 4.7kg.cm(6.0V), 5.8kg.cm(7.4V), 6.6kg.cm(8.4V)
Speed: 0.082Sec/60°, 0.067Sec/60°, 0.059Sec/60°
Working Frequency: 1520/333hz
Spline: 25T
Motor: Coreless Motor
Weight: about 20g
Size: 28.5*12*23mm
Application: For ALIGN 450/450L/470L, ALZRC 450/480/465/X360/380/420,GUAI X3 RC Helicopter
Package:
1x DEKO Digital Servo
