Detrum DVT58 25mW 5.8G 48CH FPV VTX Racing Transmitter For Racer Drone
Introduction
This is a 48 channels 5.8G 25mW wireless transmitter, installed on the aircraft, for FPV use. It is super small and lightweight, especially suitable for mini multi-rotors and lightweight aircrafts. The output power is low and the transmission distance is short, usually used in racing video transmission.
Specifications
Working Frequency: 5.8GHz ISM
Output Power: 25mW Channel: 48 CH
Input Voltage: DC 7V~17V
Supply Current: 160mA/12V
Video Input Impedance: 75Ω
Video Band Width: 8MHz
Video Format: NTSC/PAL
Working Temperature: -40~85â
Dimension (L×W×H): 32×21×9mm
Weight: 10g (without antenna)
Channel and frequency table
CH
FR
CH
CH1
CH2
CH3
CH4
CH5
CH6
CH7
CH8
FR
FR1
5865MHz
5845MHz
5825MHz
5805MHz
5785MHz
5765MHz
5745MHz
5725MHz
FR2
5733MHz
5752MHz
5771MHz
5790MHz
5809MHz
5828MHz
5847MHz
5866MHz
FR3
5705MHz
5685MHz
5665MHz
5645MHz
5885MHz
5905MHz
5925MHz
5945MHz
FR4
5740MHz
5760MHz
5780MHz
5800MHz
5820MHz
5840MHz
5860MHz
5880MHz
FR5
5658MHz
5695MHz
5732MHz
5769MHz
5806MHz
5843MHz
5882MHz
5917MHz
FR6
5362MHz
5399MHz
5436MHz
5473MHz
5510MHz
5547MHz
5584MHz
5621MHz
Features
48 channels adjustable, the channel number can be displayed on the LED digital display
Single button and single LED digital display, super small size, lightweight, portable for the aircraft
Integrated wires and plugs, easy to install
Multiple receivers can be linked at the same time, make it possible that everyone can hold a display to watch the video separately
Packing List
1 x DVT58 25mW
1 x 4-pin connector to DuPout connector and JST connector Cable
Note:
The antenna is not included, you need to purchase separately.
DVT58 must be connected with antenna when working. It is more stable and has better performance when using with 5.8G Omni-directional Mushroom Antenna.
