Specification:
Brand Name: Diatone
Item Name: GT-R530 234mm F4 OSD FPV Racing Drone
Model: GT-R530 SNX (Integrated Arm Version)
The front arm 5" SX (Stretch X) ; the rear arm 5" NX (Normal X)
Version: PNP( without receiver, battery and radio transmitter)
Wheelbase: 234mm
Arm Plate Thickness: 5mm
Color: Titanium Arm Plate Thickness: 5mm
Rated Power: 2940W
Peak Power: 3780W
| Mamba F405 Flight Controller |
Item Name: F405 Betaflight FC AIO OSD BEC Input Power: 12.6-25V (3-6S) BEC: 5V/1.5A MCU: STM32F405 Gyro: MPU6000, 8K Six-Axis Flash: 16MB OSD: AT7456 Mounting Hole: 30.5*30.5mm Weight: 6g |
| Mamba F40 DShot600 4in1 ESC |
Item Name: Mamba F40HV ESC Input Voltage: 3-6S (12.6V~25V) Continue Current: 40A×4 Burst Current: 50A (6S) BEC: NO Mounting: 30mm / φM3 Weight: 10g |
| Diatone Edge 2306 2450KV Brushless Motor |
Item Name: Edge 2306 2450KV brushless motor KV: 2450 (rpm/V) Stator Diameter: 23mm Stator Thickness: 6mm No. of Stator Arms: 12 No. of Stator Poles: 16 No-Load Current (A/10V): 2.0A Motor Resistance: 24mΩ Max. Continuous Current: 65A/10S Max. Continuous Power: 1100W Weight: 32g Outside Diameter: 23mm Body Length: 40mm Max. Lipo Cell: 3-5S |
| 5 Inch Propeller |
Item Name:5 Inch 3-Blade Propeller Color: Transparent White |
| FPV Transmitter |
TBS UNIFY 800mW VTX |
| FPV Camera |
Item Name: Runcam Micro Swift FPV Camera Image Sensor: 1/3" SONY Super HAD II CCD Horizontal Resolution: 600TV Signal System: PAL / NTSC S/N Ratio: >60dB(AGC OFF) Electronic Shutter Speed: PAL:1/50 ~ 100,000; NTSC:1/60 ~ 100,000 AutoGain Control(AGC): YES Back light compensation(BLC): YES Min.illumination: 0.01Lux/1.2F WDR: D-WDR DNR: 2DNR Day/Night: Color / Auto / B&W Power: DC 5 to 36V Net weight: 5.â6g Dimensions: 19x19x19mm |
Package Included:
1x GT-R530 F4 S&NX 234mm RC Drone ( Arm Integrated Version)
