DYS 30.5x30.5mm Flytower Omnibus F4 Pro Flight Controller + F30A 4 in 1 BLHeli_S ESC Dshot600
Description:
1. F4 Pro flight controller:
MCU: STM32F405
Gyro: MPU6000
Lipo: 2-6S
BEC output: 5V@3A
Size: 42 (L)X36(W) mm
Hole Distance: 30.5x30.5mm
Net Weight: 11.24g (not including cable)
Master STM32F405 GRT6, refresh rate up to 8K
PCB 3OZ copper enhance current stability and cooling fast
5V 3A BEC output
Exposed pad for easy soldering
Compatible with all ESCs, as well as DYS 4-in-1 esc without soldering
Integrated OSD, no need to flash firmware additionally,debug OSD via BF ground station.
Integrated current meter to monitor the real-time power consumption
Adjust the PID by OSD via remote control
Adjust the VTX via open ports such as power, frequency band, frequency point (Note: The VTX should have this function like TBS one and the upcoming - DYS VTX.)
DYS F4 flight control with 4 damping balls reduce the vibration to make it fly stably.
3.3 V Voltage output
Include PPM VTX and RSSI VTX
2. F30A 4 in 1 BLHeli_S ESC:
Continue current: 30A
Input voltage: 2-6S Lipo
BEC output: 5V/12 3A
Size: 40*30.5mm.
Weight: 12.95g(doesn't include cable and connector)
Firmware: BLHeli_S
Support Dshot150/300/600, Oneshot125/42, Multishot, PWM
With UAV conformal coating
Package Included:
1 x DYS F4 Pro flight controller
1 x DYS F30A 4 in 1 BLHeli_S ESC
