Frame | Wheelbase:142mm Top Plate Thickness: 2mm Bottom Plate Thickness: 2mm Top and Bottom Plate Spacing: 25mm FPV Camera Compatibility: 19/20mm Type:3 Inch Cinewhoop Frame With EVA Pipeline Weight:92.4g (Excluding TPU PLA) |
Flight Controller | F722 Mini Flight Controller MPU:MPU6000 CPU:STM32F722 RET6 Input Voltage:3-6S Lipo Barometer: BMP280 Flash / Blackbox: 8MB UARTS: 5 ports Firmware: EACHINEF722.HEX FC Compatibility: 20mm (M2) / 30.5mm (M3)/25.5-26.5mm(M2) Dimensions: 28.5*28.5mm Mounting: 20mm M3 |
ESC | 35A BL32 3-6S 4in1 ESC CPU:STM32F051 Input Voltage:3-6S Lipo Steady Current:35A Peak Current:40Aï¼10 Secï¼ Dimensions: 32.5*31.5mm Mounting: 20*20mm M2 Weight:6.5g |
VTX&Camera | DJI AIR UNIT Operating Frequency:5.725-5.850 GHz Input Power:7.4-17.6 V, about 4-9 W Channels:8 Weight:Air Unit (Camera included):45.8g |
Brushless Motor | 1507 2400KV Brushless Motor Motor:KV2400 (6S) Input Voltage:3-6S Recommended Prop(inch):3 Inch Weight:15.9g |
Propeller | Gemfan 75mm 3 Inch 5-Blade Propeller Quantity:4 CW & 4 CCW |
