Eachine D-moni5 5 Inch 800*480 16:9 5.8Ghz 72CH Mini FPV Monitor DVR Built-in Battery + Realacc Pagoda RHCP 5dBi & TFP-Mini 8dBi Antenna for Car Monitoring RC Drone
D-moni5 Monitor
Features
800*480 display resolution
With memory function, can save the setting when power off.
5 inch small size,easy carry, can be mount on remote controller or used as car monitor.
Single receiver with 72 channels, has covered most frequencies in 5.8Ghz bands
Support DVR function, HD recording resolution at HD(1280*720),D1(704X576),VGA(640X480)
Support video input
Support DC12V external power input
Built-in 7.4v/650MAH battery
Specification
Model : 5.8GHz 5 Inch Screen
Channel 72CH
Frequency : 5325-5945Mhz
Recieve Sensitivity : -90DBM
Screen : 5 inch
Type : 16:9 wide
Brightness : 500cd
Resolution : 800 x480
Format : PAL/NTSC
Support SD : up to 32Gb(not included)
Video Compressed Format : MPEG-4
Record Video Resolution : HD(1280*720),D1(704X576),VGA(640X480)
Battery : built in 7.4v/650MAH
Working Voltage : DC12V 300mA
Power Consumption : ≤8.64W
Working Temp. : -10â to +65â
Operation
Recording Mode :
C3: start/stop recording
C1 : long press 2 seconds into playback mode
C2 : confirm the playback of files.
Menu Mode :
Long press C2 button 2 seconds into menu;
Then long press C2 button 2 seconds into sub-menu;
Short press C2 1 second to confirm the option;
Short press C1 C3 to select the menu option;
Long press C1 2 seconds to exit sub-menu.
72CH 5.8GHZ FREQUENCY
{5865,5845,5825,5805,5785,5765,5745,5725},//Band A
{5733,5725,5771,5790,5809,5828,5847,5866},//Band B
{5705,5685,5665,5645,5885,5905,5925,5945},//Band E
{5740,5760,5780,5800,5820,5840,5860,5880},//Band F
{5658,5695,5732,5769,5806,5843,5880,5917},//Band R
{5325,5348,5366,5384,5402,5420,5438,5456},//Band U
{5474,5492,5510,5528,5546,5564,5582,5600},//Band O
{5333,5373,5413,5453,5493,5533,5573,5613},//Band L
{5653,5693,5733,5773,5813,5853,5893,5933},//Band H
ANTENNA
Pagoda Antenna
Brand Name : Realacc
Item Name : Pagoda Antenna
Color : Black/Red/White
Weigth : 9.3g
Diameter : 2.5mm
Length : 66±2mm
Frequency : 5725-5850Mhz
Impedance : 50Ω
VSWR : <1.5:1
Gain : 5dbi
Directional : omni-directional
Max. Power : 50W
Connector : SMA/RP-SMA
Lightning Protection : DC ground
TFP-Mini Triple Feed Patch
Brand Name : Realacc
Center frequency: 5.8 GHz
Bandwidth: 660 MHz (5.47 – 6.13 GHz)
Matching: S11 < -20 dB, VSWR < 1.22 (at center frequency)
Axial ratio: < 1.3
Antenna gain: 8 dBi
Half power beam width: 65° (horizontal and vertical)
Radiation efficiency: 90%
Dia.: 45mm
Package Included
1 x Eachine D-moni5 5.8Ghz 72CH 5 Inch 800*480 16:9 Small FPV Monitor for RC Drone FPV Racing Drone Car
2 x Antenna
1 x Sunshade Hood
1 x Mount
1 x Video Cable
1 x Charger
1 x Realacc Pogoda RHCP Antenna
1 x Realacc TFP-Mini Triple Feed Patch Antenna
1 x SMA Antenna Extension Cable
1 x SMA Female to RP-SMA Male Adpater
1 x SMA Male Terminal Connector
