Click here to download the manual:EV200DUserManuals.pdf
How to solve the problem of overexposure?
https://drive.google.com
Specification:
Brand Name : Eachine
Item Name : EV200D
Frequency : 5.8GHZ
Debug frequency: 5300MHz
Frequency range: 5333-5945MHz
Debug frequency: 5300MHz
Frequency range: 5333-5945MHz
Receiver Sensitivity : ≤ -93dB
Antenna Impedance : 50Ω
Audio and video: AV in/out
Video Format : NTSC/PAL
Brightness: adjustable
Contrast: adjustable
Pupil Distance adjusting: 56-72mm
Power input: 7.4v
Minimum voltage: 6.8v
Operating temperature: -10°C-40°C
Audio and video: AV in/out
Video Format : NTSC/PAL
Brightness: adjustable
Contrast: adjustable
Pupil Distance adjusting: 56-72mm
Power input: 7.4v
Minimum voltage: 6.8v
Operating temperature: -10°C-40°C
Features:
FOV 42°
Built-in DVR
USB power supply
Resolution 1280*720
7.4V battery with LED indicator
Aspect ratio 16:9/4:3,Default display is 16:9
Supported display mode: HD Port in 2D/3D; AV in 2D/3D
IPD adjustable 56mm-72mm: Adjustable,wide-ranging IPD,suits more pilots
Optional diopter lens,compatible with Fatshark diopter lens,200/400/600 degrees selectable(diopter lens not include)
Dual true diversity,supports open source RX modules
Package included:
1 x EV200D goggles
1 x Zipper case
1 x 7.4v 1800mAh Battery
1 x Sponge
2 x FPV receiver (optional)
1 x USB Cable
1 x HD Port Cable
1 x Lens wiping cloth
1 x User Manual
Note: Set B includes 2*True diversity receivers
