Note: The goggles upgraded version with the face sponge and AV IN function . The Headphone jack was changed to 3.5mm. The total weigh reduction of 26g.
Specification |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Brand name |
Eachine | |||||||||||||||||||||||||||||||||||||||||||||||||||||||
Item No. |
EV800 | |||||||||||||||||||||||||||||||||||||||||||||||||||||||
Screen |
Screen size: 5.0 inch Screen resolution: 800*480 (No blur after enlarge by the lens) Screen brightness: 600cd/m2 with special high brightness backlight LED for outdoor FPV View Angle: 140/120 degree(Horizontal/Vertical) |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||
Lens |
3x boost of the video to acquire intense feel-in-there video; 92% transparent rate no distort of light; |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||
Battery and recharge |
Built-in 3.7V/2000mAh battery; Each battery circle offer around 3.5hr working time; 5-12V wide recharging voltage range, typical recharging voltage is 5V Accepts 5V power banks or 2S(7.4V)/3S(11.1V) battery as back-up power to have long working time |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||
Receiver |
Build in 5.8G 40CH Raceband receive
|
|||||||||||||||||||||||||||||||||||||||||||||||||||||||
Body |
Dimension: 180x145x82mm Weight: 349g with 3.5hr 2000mAh battery Belt: three-ways adjustable belt |
Feature:
- With comfortable face sponge and AV IN function;
- Separable design, 5 inch screen can be used as small monitor on radio controller or with tripod;
- HD high brightness 5inch LCD specially tuned for FPV racing;
- Built-in super sensitiveness 5.8GHz 40ch receiver, especially with RaceBand;
- Come with advanced auto-searching function ad show you the working frequency on screen;
- Built-in 3.7V/2000mAh battery, each full charge revive around 3.5hours working time;
- Wide range re-charge voltage 5-12V, power banks or 2S/3S batteries can be used as back-up power sour, to prolong the working time;
- Ergonomic design fit your faces;
- Super-wide visible angle up to 82 degree;
- 92% transparent lens adopted, no distort, no blur on the adage of screen;
- Light weight 375g with 3.5hr 2000mAh battery, RTF for any scale racing game.
- 5 inch 800*480px HD high brightness LCD
Package Included:
1 X EV800 FPV VR Goggles (Built-in 3.7V/2000mAh battery)
1 X Mushroom Antenna
1 X USB charger cable
1 X Battery charger cable
1 X AV IN cable
1 X User Manual
1 X Clean cloth
1 X Bag
, , , , , , ,
