Description:
Brand Name: Eachine
Item Name: Mirage E500
Version: BNF Version
Color: Grey
Compatible Receiver: Flysky, Frsky, DSM2 (optional)
Material: EPP
Wingspan: 500mm
Length: 260mm
Fuselage Height: 85mm
Winglet Height: 163mm
Motor: 1806 2300KV Brushless *2
Servo: 3.7g *2
Propeller: 5030 two leaf self-locking
Battery: 2S 7.4V 600mAh 25C LiPo
Flight Difficulty: General
Working Enviroment Temperature: -10â ~ +40â
Flight Weight: 180g
CG: 125-135mm from the trailing edge of the wing
Flying Speed: Up to 100km/h
Flight Mode: Vertical flight mode,horizontal flight mode
Servo Specifications:
Weight: 3.7g
Size: 20x24x9mm
Operating Voltage: 5.0V DC
Rated Torque: 5.0V ≥0.26kgf·cm
No Load Speed: 5.0V ≤0.13sec/60°
Pulse Width Range: 800-2200μs
Median: 1500μs
Operating Angle: 100° ± 10° (1000 - 2000μs)
Maximum Operating Angle: 140° ± 10° (800 - 2200μs)
Dead Zone Width: ≤ 15μs
Operating Temperature: -10â ± 50â
Recommended Parts For Eachine Mirage E500 (Not Included):
Charger: Balance charger, Click Here
Radio Control: 2.4G 6CH Transmitter, Click Here
Camera: 1000TVL camera, Click Here
Vtx: 5.8G 200mw 40CH, Click Here
FPV Goggle: Eachine VR006, Click Here
Features:
Three kinds of receiver optional - Flysky, Frsky and DSM2 compatible receiver.
EPP material, safe,lightweight and drop-resistant.
Aerodynamics design,making the flight faster,more stable and more comfortable.
With powerful 1806 2300KV brushless motor,the flight speed is up to 100km/h.
Can do vertical takeoff / suspension flight,horizontal flight mode,self-propelled flight,low-speed cruise flight,360° stunt flight,indoor flight and hand-throwing flight.
Support flight mode one key switch.
Comes with a 2S 7.4V 600mAh 25C LiPo battery and USB balance charger.
Note:
The BNF version does not come with the transmitter and FPV equipments.
Package Included:
1x Eachine Mirage E500 Airplane BNF
1x Battery
1x USB Balance Charger
1x Decals
Recommended Parts For Eachine Mirage E500 (Not Included):
Charger: Balance charger, Click Here
Radio Control: 2.4G 6CH Transmitter, Click Here
Camera: 1000TVL camera, Click Here
Vtx: 5.8G 200mw 40CH, Click Here
FPV Goggle: Eachine VR006, Click Here
Features:
Three kinds of receiver optional - Flysky, Frsky and DSM2 compatible receiver.
EPP material, safe,lightweight and drop-resistant.
Aerodynamics design,making the flight faster,more stable and more comfortable.
With powerful 1806 2300KV brushless motor,the flight speed is up to 100km/h.
Can do vertical takeoff / suspension flight,horizontal flight mode,self-propelled flight,low-speed cruise flight,360° stunt flight,indoor flight and hand-throwing flight.
Support flight mode one key switch.
Comes with a 2S 7.4V 600mAh 25C LiPo battery and USB balance charger.
Note:
The BNF version does not come with the transmitter and FPV equipments.
Package Included:
1x Eachine Mirage E500 Airplane BNF
1x Battery
1x USB Balance Charger
1x Decals
