Notice:
1. This is the DIY version that comes unassembled.
2. Comes without battery, charger, receiver or radio transmitter.
Specification:
Brand Name: Eachine
Model: Tyro119
Item Name: 250mm F4 OSD 6 Inch 3-6S DIY FPV Racing Drone
Version: PNP ( Without Receiver, Battery and Radio Transmitter)
Item | Specification |
250mm Racing Frame Kit |
Wheelbase: 250mm
Frame arm thickness: 5mm
Frame kit material: 3K carbon fiber
|
Eachine 2407 1800KV Motor |
KV: 1800KV
Lipo: 3-6S
|
Eachine GPS F4 Flight Controller |
Brand Name: Eachine
Model: GPS F4
Main control chip: STM32F405
Gyroscope: MPU6000
Barometer: BMP280
Firmware: Support betaflight / INAV firmware
Integrated OSD, support betaflight configuration & DMA Mode ( F4 MCU controls OSD)
- Support PPM /DSM2/X / IBUS/ SBUS/ XBUS receiver
- with 10V @ 1.2A BEC Output, for VTX or Camera
|
Eachine 40A 4In1 BLHeli_S ESC |
Continuous Current: 40A
Burst current: 45A (10S)
BEC output: 5V @ 2A
Input voltage: 2-6S
Main control chip: 48mhz EFM8BB2
Firmware upgrade: Supports Dshot150-600/Multishot/Oneshot/PWM
MOS: 5X6
Current Sensor: NO
Size: 37.5x37.5mm
Mounting Hole: 30.5x30.5mm
Weight: 15g
|
DALProp TJ6045 3-blade propeller |
Brand Name: DALProp Model: TJ6045 Item Name: 6045 6 Inch 3-Blade Propeller Color: Black Quantity: 2 CW & 2 CCW |
5.8G 40CH 0/25/200/600mW VTX |
Transmitting power:0/25/200/600mW switchable
Channel: 40CH
Full video format: NTSC/PAL
|
Caddx.us Turbo f2 Camera |
Case size: 19x19x16mm
Weight: 5.5g
Signal system: NTSC / PAL (Switchable)
Resolution ratio(horizontal center): 1200TVL
Video output Signal: cvbs
Image: 16:9
Synchronization method: inter-sync
Camera lens: standard 2.1mm
Lens operating voltage: DC 4.5-40V
S/N Ratio: >52dB (AGC OFF)
Audio: YES
|
BN-220T GPS Module |
Brand Name: Beitian Model: BN-220T |
Recommend Lipo Battery | 5S 1300-1800mAh 50-85C Lipo Battery |
Package Included:
1x Tyro119 DIY Drone PNP
