Description:
Brand Name: EWRF
Item Name: e7082VM VTX with Camera Combo
Specifications of FPV VTX:
Frequency: 5.8G 40CH
Transmitting Power: 25mw/100mw/OFF(Pitmode)
Power Supply: DC5V
Current(5v): 190mA(25mw) / 270mA(100mW)
Antenna: UFL
Weight: 1.9g
Standard Size: 14*15*3mm
Specifications of Camera:
Sensor Size: 1/4''
Focal Length: 0.95mm
F/NO: 2.0
Back Focal Length: 2.11mm
Flange Back Length: 1.66mm
Field of View: 160°
Optical Distortion: <8.5%
Thread Size: M7XP0.35
Element: 2G2P+IR
Optical Layout: 5:1
Features:
- With button to select the power.
- Betaflight/Cleanflight OSD configuring parameter
- Clean powerup and channel switching without interference to others
- Smaller current,100mw 5V power supply 270mA
Frequency (Mhz):
| Band | CH1 | CH2 | CH3 | CH4 | CH 5 | CH6 | CH7 | CH8 |
| A | 5865 | 5845 | 5825 | 5805 | 5785 | 5765 | 5745 | 5725 |
| b | 5733 | 5752 | 5771 | 5790 | 5809 | 5828 | 5847 | 5866 |
| c | 5705 | 5685 | 5665 | 5645 | 5885 | 5905 | 5925 | 5945 |
| d | 5740 | 5760 | 5780 | 5800 | 5820 | 5840 | 5860 | 5880 |
| E | 5658 | 5695 | 5732 | 5769 | 5806 | 5843 | 5880 | 5917 |
Package Included:
1x EWRF e7082VM 5.8G 40CH FPV Transmitter
1x 800TVL camera
