Description:
FPV Camera:
Color: Red, Black (optional)
Lens: 1.66mm
Image Sensor: 1/1.8" Inch starlight HDR sensor
Horizontal Resolution: 1200TVL
FOV: 150 Degree
Min. Latency: 8ms
TV System: NTSC & PAL (changeable)
Image: 16:9 & 4:3 (changeable)
WDR: WDR (HDR)
Min. Illumination: Starlight
Synchronization: Internal
Electronic Shutter: PAL: 1/50~100,000; NTSC: 1/60~100,000
S/N Ratio: >60dB (AGC OFF)
Video Output: CVBS
Camera OSD: Separate OSD
DNR: 3-DNR
Day/Night: Auto/Color/B&W/EXT
Language: Chinese/English
Dimensions: 19mm*19mm*19mm
Wide Energy Input: DC 5-40V
Work Temperature: -20â~+60â
Work Humidity: 20%~80%
Weight: 8g (N.W.)/ 40.5g (G.W.)
FPV Transmitter:
Model: EWRF e709TM3 Pro
Working frequency: 5.8GHz
Working channel: 40CH
Transmit power: 25/200/500/800/Launch off ( Pit mode)
Operating voltage: DC7-26V
Working current:
90mA(25mW)/130mA(200mW)/220mA(500mW)/300mA(800mW)
Antenna: MMCX
Weight: 4.4g
Dimensions: 29.9*21.7*4.85mm
Features:
- 1/1.8" inch sensor starlight camera
- 8ms low latency, 0.0001lux illumination
- Red and black two colors optional
- NTSC/PAL switchable, 16:9/4:3 changable
- Separate OSD
Package Included:
1x FPV Camera
1x 5D-OSD Menu Board
1x FPV Silicone Cable A (3-pin port for both side)
1x FPV Silicone Cable B (2-pin port for both side)
1 x FPV Transmitter
1 x FPV Antenna
