Specification:
Brand name: Flycolor
Item name: Raptor S-TOWER F4 20A Flytower
Con. Current: 20A
Burst Current(10S): 30A
F.C Vout: 3.3V 5V 12V
Lipo cells: 2-4S
Weight: 14.6g
Size: 31.6x31.2x17mm
Mounting holes: 20x20mm
Typical Applications: 120-180Multi
ESC
â EFM8BB21F16G MCU, pipelined 8-bit C8051 core with 50 MHz maximum operating frequency. ESC maximum speed is limited to 500k eRPM.
â Dedicated 3in1 drivers, makes the start more smooth.
â ESC ï¬rmware: BLHeli-S,F-H-40.
â Two layers tower structure between 4in1 ESC and FC, using cable for quick connection, silicon spacer for supporting could reduce the eï¬ect of vibration on Flight Controller, makes the ï¬ight more stable.
â BLHeli-S ï¬rmware. It is designed for superior performance in multirotors, and uses hardware generated motor pwm for smooth throttle response and silent operation.
â The code supports regular 1-2ms pulse width input, as well as Oneshot125 , Oneshot42 and Multishot .
â Supports Dshot150, Dshot300 and Dshot600.Dshot is digital signal, anti-interference ability is stronger, and do not need throttle calibration.
Flight Controller
â MCU: STM32F405.
â Gyro: MPU-6000 SPI.
â FC ï¬rmware: Betaï¬ight_OMNIBUSF4
â Supports PPM,SBUS,SPEKTRUM1024/2048 etc. remote control / receiving mode.
â FC integrated OSD, users can adjust OSD parameters via Betaï¬ight conï¬gurator.
â FC integrated 3.3V,5V, 12V and VBAT for receiver, VTX, camera, buzzer, LED and other peripheral devices.
â Provided several cables for peripheral devices such as VTX, camera etc. And will give you an unprecedented experience for assembly.
â Install holes: 20x20mm,M2.
Package Included:
1 x Raptor S-TOWER F4 20A Flytower
