OVERVIEW:
The FGr4P uses AFHDS 3(Third Generation Automatic Frequency Hopping Digital System). It uses a single antenna with two-way transmission capabilities and is designed to be compact and easy to install. It can output standard PWM, i-BUS and PPM.
Description:
Brand Name: FlySky
Item Name: FGr4P Receiver
Dimensions: 29 * 22 * 16.2mm
Weight: 20g
PWM channels: 4CH
Wireless frequency: 2.4GHz
Wireless protocol: AFHDS 3
Range:> 200m (ground)
Antenna type: single antenna (150mm)
Power: 3.5-8.4V
RSSI: Supported
Data port: PWM / PPM / i.bus / s.bus
Temperature range: -10 â — + 60 â
Humidity range: 20% -95%
Online Update: Yes
Certification: CE, FCC ID: N4ZFGR4P00
Binding:
Package Included:
1 x FGr4P Receiver
CH 1-CH 4: Connects the servos, power supply or other components
i-BUS: for channel expansion or connect sensors
BIND: For bind cable
Battery: Connect the battery
Binding:
1. Insert the bind cable into the receivers bind port
2. Plug the power cable into any other port, and the receivers LED will start to flash quickly indicating that it has entered bind mode
3. Put the transmitter into bind mode; (See the transmitters instruction manual for more information)
4. Binding is successful when the receivers LED will stop flashing
Remove the power and bind cables from the receiver.
5. Reconnect the power cable to the receiver
6. Check to make sure that the transmitter and receiver are working as expected, if there are any issues or unexpected operation follow the steps above to bind again.
Attention:
Make sure the product is installed and calibrated correctly, failure to do so may result in serious injury.
Make sure the receiver's battery is disconnected before turning off the transmitter, failure to do so may lead to unintended operation or loss of control.
Make sure the receiver is mounted away from motors, electronic speed controllers or any device that emits excessive electrical noise.
Keep the receiver's antenna at least 1 cm away from conductive materials such as carbon or metal.
Do not power on the receiver during the setup process to prevent loss of control.
1 x FGr4P Receiver
