The fgr4 S uses afhds3( Third Generation Automatic Frequency Hopping Digital System). It uses a internal single antenna with twoway transmission capabilities and is designed to be compact and
easy to install, It can output standard PWM, i-BUS and PPM
Item Brand:FlyskyItem Number:FGr4S
Item Name:Receiver
Material:Plastic and electronic components
Color:
Product Size:25.5 22*17.3 mm
Product Weight:About 5.1g
Packaging Weight:Approx.8g
Fit For:Flysky NB4 and PL18 transmitter
Specification:
Channels:4
Model Type: Car/Boat
Data Output: PWM/i-BUS/PPM
Frequency Range: 2.402-2.480GHZ
Transmission Power: <20dBm(EU)
RF Standard: AFHDS3
Antenna: Built-in Antenna
Input Power: 3.5V 8.4V
Display: LED Indicato
Online Update: Yes
CH 1-CH 4: Connects the servos, power supply
other components
i-BUS: for channel expansion
BIND: For bind cable
Certification: CE, FCC ID: N4ZFGRS400
Package included:
Binding:
To ensure good signal strength, make sure the receiver antenna is as far away from any metal parts when installing the receiver
1. Insert the bind cable into the receivers BIND port;
2. Plug the power cable into any other port, and the the receiver's LED will start to flash quickly indicating that it has entered bind mode
3. Put the transmitter into bind mode; (See the transmitter'sinstruction manual for more information
4. Binding is successful when the receiver's LED starts to flash slowly. Remove the power and bind cables from the receiver
.If the transmitter is bidirectional the reciever status indicator
will not fash slowly
5. Reconnect the power cable to the receiver
6. Check to make sure that the transmitter and receiver are working as expected, if there are any issues or unexpected operation follow the steps above to bind again
