Specification:
Brand Name: Flywoo
Model: ROBO 1204
Item Name: 1204 5150KV 3-4S / 8150KV 2-3S Brushless Motor
Quantity: 1 PC
KV: 5150KV/ 8150KV (Optional)
Input Voltage: 3-4S@ 5150KV; 2-3S@8150KV
Configuration: 9N12P
Stator Diameter: 12mm
Stator Length: 4mm
Shaft Diameter: 1.5mm ( 2mm Inside)
Motor Dimension: 15.26x10.9mm (Dia*Len)
Weight: 5g ( 15cm wire)
Idle Current(10) @10V: 1A @5150KV; 1.5A @8150KV
Max. Con. Power (3S): 115W@ 5150KV; 142W@8150KV
Internal Resistance: 125mΩ@ 5150KV; 95mΩ@8150KV
Max. Current (3S): 7.8A@ 5150KV; 12.8A@8150KV
Package Included:
1x Flywoo ROBO 1204 Motor
2x M2*7 Screws
4x M2*5 Screws
