FPV 1/3 CCD 700TVL 2.8mm Micro Camera Mini 25mm*25mm PAL NTSC 12V with OSD Button For FPV Racer
Description :
Color : Black, Silver, Blue, Purple
CCD : 1/3 Sony 960H CCD Sensor
Pixel : PAL: 1020H×596V (0.61MP) NTSC: 1020H×508V (0.52MP)
Effective Pixel : PAL: 976H×582V (0.57MP) NTSC: 976H×494V (0.48MP)
Format : PAL/NTSC
Resolution (horizontally) : 700TVL
DNR : 2DNR, support 0~15, 16 grades adjustable
LUX : 0.01LUX/F1.2
SNR : ≥48dB
Video Output : 1.0Vp-p/75Ω
AGC : 0.25/0.50/0.75/1.00 4 grades adjustable, up to 55dB
WB : ON/OFF
BLC : HLC / Backlight Compensation
Exposure Mode : EE
Electronic Shutter : 1/50(1/60) - 1/100000 sec
Gamma Correction : 0.45/1.0
Synchronization Mode : Internal Synchronization
Audio : NO
Lens : 2.8mm
Working Voltage : DC12V±5%
Working Temp.: -20â--60â
Wetness : 0%~96%
Size : 25mm*25mm
Package Included:
1 x Camera
