Overview:(Transmitter)
Horus X10S Express use the ACCESS communication protocol, it boasts 24 channels with a faster baud rate and lower latency equipped with a high-speed module digital interface. Along with the new spectrum analysis function and added FrOS/OpenTX firmware, it is now possible to check the airwaves for RF noise.
Both X10 and X10S Express support balancing charge for 2S Li-ion battery via a collateral USB cable. The accessible battery compartment design is another change worth mentioning, with two 18650 Li-ion batteries you can expect to be able to fly whole day. The Express carries forward all of their predecessor’ features like the industrial LCD color screen, and the highly-accuracy M10/MC12P hall sensor gimbals which offer the most precise control. Additionally, it features a remarkable PARA wireless trainer function which also makes them compatible with the FrSky Free Link App and AirLink S. All that makes the Express version an ideal transmitter for, gliders, helis, multirotor and every type of fixed-wing imaginable.
Note:
The X, XM, RX, GX series receivers can be gradually upgarded to ACCESS protocol. It includes XM, RXSR, RX4R, RX6R, G-RX6, G-RX8, XM Plus, and R9 series. For more details about ACCESS, pls. visit: https://www.frsky-rc.com/frsky-advanced-communication-control-elevated-spread-spectrum-access-protocol-release/
Overview:(Module)
Note:
The X, XM, RX, GX series receivers can be gradually upgarded to ACCESS protocol. It includes XM, RXSR, RX4R, RX6R, G-RX6, G-RX8, XM Plus, and R9 series. For more details about ACCESS, pls. visit: https://www.frsky-rc.com/frsky-advanced-communication-control-elevated-spread-spectrum-access-protocol-release/
Overview:(Module)
FrSky R9 and R9M radio control system is the first FrSky long range system which works in the frequency of 900MHz. The R9M module offers 4 switchable RF power outputs to so you can choose the appropriate power for different flight situations. Compared to another FrSky 2.4GHz long range receiver like the L9R, the R9 receiver has a longer operating range up to 10KM and above. Moreover, the R9 is also a redundancy receiver which can connect to another receiver to ensure the security of your aircraft.
Note:
If S.Port is disabled, communication related to S. Port between R9M 2019 and the transmitter will be cut off.
SPECIFICATIONS:(TransmitterManual)
Brand: FrSky
Item name: Horus X10S Express Transmitter
Dimension: 213*225*112mm (L*W*H)
Weight: 950g (without battery)
Operating system: FrOS / OpenTX
Internal RF module: ISRM-S-X10
Number of Channels: 24 channels
Operating Voltage: 6.5 ~ 8.4V (2S Li-battery)
Operating Temperature: -10â- 60 â (14â -140â )
Operating Current: [email protected] (typ)
Charging Current: ≤1A ±200mA
USB Adaptor Voltage: 5.0+0.2V
USB Adaptor Current: >2.0A
Backlit LCD resolution: 480*272
Compatibility: ACCST D16 and ACCESS receivers
FEATURES:
High-speed module digital interface with installed ACCESS protocol
Supports spectrum analyzer function
Supports wired training function
New PARA wireless training system
– High-speed training system with a lower latency
– Compatible with FrSky Free Link App and AirLink S via mobile devices
2 internal antennas and detachable external antenna
Antenna detection and SWR warning
Industrial LCD: 480*272 readable outdoor color screen
Supports 2S Li-battery balancing charge with Mini USB interface
Easily accessible battery compartment (*Batteries not included)
MC12P all CNC digital higher accuracy ten bearings hall sensor gimbals and extendable stick ends
Specification:User Manual
Package included:
1 x Horus X10S Express Transmitter
1 x R9M 2019 Transmitter Module
Specification:User Manual
Brand: FrSky
Item Name: R9M 2019 900MHz Transmitter Module
Vin Voltage Range: 6.5V-13V
External Power Supply: 6.5V~13V
Telemetry Interface: Smart Port
Upgrade Interface: Smart Port
Modulations: PXX or CPPM (auto-detected)
RF Operating Frequency: 915MHz
Compatibility : R9 Series Receivers
Feature :
-900MHz/868MHz Working Mode
-Long Range, Low Latency and High Precision RC System
-4 Optional RF Power (Non-EU Version)
-Telemetry Mode (25mW)/Non-telemetry Mode (200mW / 500mW) (EU Version)
-RF Power (Flex): 10mW/ 100mW/ 500mW/ 1W (telemetry supported for all levels)
-Smart Port Enabled and Support Telemetry Data Transmission
How to enable/disable the S.Port of R9M 2019(Non-EU) Module
-- For Taranis Series transmitters, if you want to turn on the S.Port of R9M 2019, turn off the Internal RF.
-- For Horus Series transmitters, turn on the transmitter. go to the RF SYSTEM, choose the External RF
and select R9M, then choose S.Port or not.
Package included:
1 x Horus X10S Express Transmitter
1 x R9M 2019 Transmitter Module
