Geprc GR2306 2306 2450KV 2750KV 3-5S Brushless Motor for RC Drone FPV Racing - 21.90 €

Seller: Banggood,
Ship from: CN Warehouse, Usually dispatched in 1-3 work days.

FREE SHIPPING: 10-35 days. (DHL faster please check price/quantity first)

Free shipping aviable, Registered postage from 25 €

Geprc GR2306 2306 2450KV 2750KV 3-5S Brushless Motor for RC Drone FPV Racing

Specification:
Brand Name: Geprc
Model: GR2306
Item Name: 2306 2450KV 2750KV 3-5 Brushless Motor
KV: 2450KV / 2750KV ( Optional)
Screw Thread: CW Screw Thread
Lipo Input: Support 3-5S Lipo

Configuration:12N14P

Stator Diamter:23mm

Stator Length:6mm

Shaft Diameter:4mm(Hollow)

Motor (Dimension(Dia.*Len)):Φ 28.49*30mm

Idle current(10)@10V(A):2.1 (2450KV) ; 2.6 (2750KV)

of Cells(Lipo):3~5S

Max Continuous (Power(W)15S):950

Internal Resistance:33mΩ (2450KV) ; 26mΩ (2750KV)

Max Current(15S):45A

Effciency Current:(4-8A)>81%

Rotor: N52H arc magnets

Bearings:NSK

Base casing: Al 7075

Wire AWG: 20AWG

Weight(g):32

Features:

- Super light base design and strong power take-off

- Elegant appearance design, strong airstream, stout structure and anti-impact

- The whole fuselage is high-precision CNC processing; the aviation aluminum alloy is 7075 aluminum materials, which is high precision and high intensity

- The maximum pull with 2750kv breaks through 1800g+

Package Included:
1x GR2306 Motor
