Happymodel EX1103 1103 6000KV 8000KV 12000KV 2-4S Brushless Motor for Sailfly-X Toothpick RC Drone - 9.00 €

Happymodel EX1103 1103 6000KV 8000KV 12000KV 2-4S Brushless Motor for Sailfly-X Toothpick RC Drone
Seller: Banggood,
Ship from: CN Warehouse, Usually dispatched in 1-3 work days.

FREE SHIPPING: 10-35 days. (DHL faster please check price/quantity first)
Free shipping aviable, Registered postage from 25 €


Happymodel EX1103 1103 6000KV 8000KV 12000KV 2-4S CW Brushless Motor for RC Drone FPV Racing

Specification:
Brand Name: Happymodel
Model: EX1103
Item Name: 1103 6000KV 8000KV 12000KV 2-4S Brushless Motor
KV: 6000KV / 8000KV / 12000KV (Optional)
Version: CW ( Red Cable)
No. of Cells (Lipo): 6000KV @ 3-4S ; 8000KV @ 2-3S ; 12000KV @ 1-2S
Configu-ration: 9N12P
Stator Diamter: 11mm
Stator Length: 3mm
Shaft Diameter: Φ1.5mm
Motor Dimension(Dia.*Len): Φ13.5mm*16mm
Weight: 3.7g
Application: compatible with 105mm-110mm RC Drone

Features:
- High efficiency and smooth
- Dual bearing design and more balance
- Better for Toothpick building
- Compatible with 40mm-75mm propellers

Testing Table:
Model No Load Propeller Voltage
(v)
Currents
(A)
Thrust
(g)
Power
(W)
Efficiency
(g/W)
Throttle
6000KV 0.12A 12080RPM 1935 tri-blades 14.8 1 42.7 14.8 2.885 1399
14.8 2 74.6 29.6 2.520 1571
14.8 3 95.3 44.4 2.146 1711
14.8 4 117.6 59.2 1.986 1827
14.8 4.4 124.6 65.12 1.913 1922
6000KV 0.14A 11580RPM 65mm bi-blades 14.8 1 53.2 14.80 3.595 1495
14.8 2 92.5 29.60 3.125 1683
14.8 3 121.7 44.40 2.741 1829
14.8 4 148.7 59.20 2.512 1952
14.8 4.6 157.5 68.08 2.313 2200
8000KV 0.25A 15720RPM 1935 tri-blades 11.1 1 32.8 11.1 2.955 1399
11.1 2 56.6 22.2 2.550 1571
11.1 3 76.6 33.3 2.300 1711
11.1 4 92.8 44.4 2.090 1827
11.1 5 109.2 55.5 1.968 1922
11.1 5.9 122.3 65.49 1.867 2200
8000KV 0.20A 15650RPM 65mm bi-blades 11.1 1 36.8 11.1 3.315 1397
11.1 2 67.3 22.2 3.032 1585
11.1 3 91.3 33.3 2.742 1707
11.1 4 111.2 44.4 2.505 1837
11.1 5 128.3 55.5 2.312 1941
11.1 5.8 139.1 64.38 2.161 2200
12000KV 0.44A 24750RPM 65mm bi-blades 7.4 1 22.5 7.4 3.041 1298
7.4 2 40 14.8 2.703 1425
7.4 3 58.4 22.2 2.631 1554
7.4 4 72.3 29.6 2.443 1649
7.4 5 87.6 37 2.368 1750
7.4 6 98.6 44.4 2.221 1830
7.4 7 109.3 51.8 2.110 1918
7.4 8 119.9 59.2 2.025 1988
7.4 8.3 121.2 61.42 1.973 2200
12000KV 0.44A 24750RPM 1935 tri-blades 7.4 1 18.6 7.4 2.514 1298
7.4 2 32.8 14.8 2.216 1425
7.4 3 47.8 22.2 2.153 1554
7.4 4 59.7 29.6 2.017 1649
7.4 5 72.4 37 1.957 1750
7.4 6 83.2 44.4 1.874 1830
7.4 7 92.6 51.8 1.788 1918
7.4 8 101.8 59.2 1.720 1988
7.4 8.2 103.8 60.68 1.711 2200

Package Included:
1x Happymodel EX1103 Motor
