HD Digital Transmission System
4K UHD/1080P Lite Pro/Pro 1080p FHD
HDMI 5G 10KM Wireless Video Transmission 4H Working Time Built-in 3000mAh LiPo
Specification:
Model: Pro 4K UHD
Transmission range (outdoor): standard antenna 500m
Output delay: 50-60ms
Frequency: 5.1GHz-5.8GHz
Modulation: OFDM
Input/output interface: Mini HDIM
Input video format: HDIM 4K UHD@30, compatible with 1080P@30@60
Output format: HDIM 4K UHD@30
Compression ratio: HEVC 3A TV broadcast level
Channels: 24 channels
Supported device: HDIM display, mobile phone, tablet, computer (requires WIFI support 802.11n/ac)
Supported system: Windows, Android, iOS
Data interface: USB, UART serial port data transparent transmission interface
PWM: 6 sets of PWM signal output PTZ and other external equipment control
Encryption: 256 bit encryption
Operating temperature: -20â~60â
Certification: FCC, CE standards
Charging port: type-c 5V charging port
Battery: (receiver/transmitter) built-in 3000mAh Li-Po battery (continuous work for 4 hours/2.5 hours)
Size: (116.9 SMA connector included) 112.6*64.6*31.5mm, weight 220g
Model: 1080P Lite Pro
Transmission range (outdoor): standard antenna 100m
Output delay: 50-60ms
Frequency: 5.1GHz-5.8GHz
Modulation: OFDM
Input/output interface: Mini HDIM
Input video format: HDIM full format up to 4K UHD @30
Output format: 1080P@30@60
Compression ratio: HEVC 3A TV broadcast level
Channels: 24 channels
Supported device: HDIM display, mobile phone, tablet, computer (requires WIFI support 802.11n/ac)
Supported system: Windows, Android, iOS
Data interface: USB, UART serial port data transparent transmission interface
PWM: 6 sets of PWM signal output PTZ and other external equipment control
Encryption: 256 bit encryption
Operating temperature: -20°C~60°C
Certification: FCC, CE standards
Charging port: type-c 5V charging port
Battery: built-in 3000mAh Li-Po battery (continuous work for 4 hours)
Size: (116.9 SMA connector included) 112.6*64.6*31.5mm, weight 220g
Model: PRO 1080P FHD
Transmission range (outdoor): standard antenna 100m
Output delay: 50-60ms
Frequency: 5.1GHz-5.8GHz
Modulation: OFDM
Input/output interface: Mini HDIM
Input video format: HDIM full format up to 4K UHD @30
Output format: 1080P@30@60
Compression ratio: HEVC 3A TV broadcast level
Channels: 24 channels
Supported device: HDIM display, mobile phone, tablet, computer (requires WIFI support 802.11n/ac)
Supported system: Windows, Android, iOS
Data interface: USB, UART serial port data transparent transmission interface
PWM: 6 sets of PWM signal output PTZ and other external equipment control
Encryption: 256 bit encryption
Operating temperature: -20°C~60°C
Certification: FCC, CE standards
Charging port: type-c 5V charging port
Battery: built-in 3000mAh Li-Po battery (continuous work for 4 hours)
Size: (116.9 SMA connector included) 112.6*64.6*31.5mm, weight 220g
Package List:
1 x Digital Image Transmission Set
