Main Features:
Usage: for 65 - 250mm frame kit
Specifications:
Micro F4 Flight Control Board ( DShot Version )
MPU: MPU6000 ( SPI )
CPU: STM32F405RGT6, dual 8K
Black box: 16M flash
Input voltage: 2 - 4S LiPo
Built-in BetaFlight OSD to adjust PID
BEC output: 5V at 3A
Size: 25 x 25mm board, 20mm mounting holes ( M2 )
Weight: 3.7g
Support SUBS / PPM / DSMX receiver
2 - S BLHeli - S BB2 4-in-1 ESC:
Input voltage: 2 - 4S LiPo battery
Constant current: 33A
Peak current: 38A
BEC output: no
Firmware: BLHeli - S 16.5
Size: 27 x 27mm ( main board ), 32 x 32mm ( including pad )
Installing hole: 20 x 20mm, M2
Weight: 4.7g
CPU: SILABS EFM8BB2 48MHz
Firmware: BetaFlight 16.5
Support Damped Mode, Oneshot125, Oneshot42, Multishot, Dshot150, Dshot300, Dshot600, forward and reverse
Usage: for 65 - 250mm frame kit
Specifications:
Micro F4 Flight Control Board ( DShot Version )
MPU: MPU6000 ( SPI )
CPU: STM32F405RGT6, dual 8K
Black box: 16M flash
Input voltage: 2 - 4S LiPo
Built-in BetaFlight OSD to adjust PID
BEC output: 5V at 3A
Size: 25 x 25mm board, 20mm mounting holes ( M2 )
Weight: 3.7g
Support SUBS / PPM / DSMX receiver
2 - S BLHeli - S BB2 4-in-1 ESC:
Input voltage: 2 - 4S LiPo battery
Constant current: 33A
Peak current: 38A
BEC output: no
Firmware: BLHeli - S 16.5
Size: 27 x 27mm ( main board ), 32 x 32mm ( including pad )
Installing hole: 20 x 20mm, M2
Weight: 4.7g
CPU: SILABS EFM8BB2 48MHz
Firmware: BetaFlight 16.5
Support Damped Mode, Oneshot125, Oneshot42, Multishot, Dshot150, Dshot300, Dshot600, forward and reverse
Specification
General |
Type: Flight Controller Set |
|---|---|
Dimension and Weight |
Product weight: 0.0084 kg
Package weight: 0.0166 kg Product size (L x W x H): 3.20 x 3.20 x 3.20 cm / 1.26 x 1.26 x 1.26 inches Package size (L x W x H): 4.00 x 4.00 x 4.00 cm / 1.57 x 1.57 x 1.57 inches |
Package Contents |
Package Contents: 1 x F4 Flight Controller, 1 x ESC, 4 x M2 17 Screw, 4 x M2 Screw Nut |
