Description:
The main board has flight controller, OSD, PDB, video transmitter and voltage / current sensor all highly integrated. This enables us to get all those components assembled easily without additional welding.
Main Features:
- Flight controller, OSD, PDB, FPV transmitter and voltage / current sensor are all integrated in one PCB
- 5.8GHz, 200 / 600mW switchable, 40-channel video transmitter with built-in push button and channel display ( on LED board )
- Integrated MWOSD ( firmware V1.5 pre-loaded )
- Compatible with SBUS, DSMX, and PPM receivers
- BetaFlight pre-loaded
Specifications:
- STM32F303CCT6Â 32-bit processor with 256KB flash
- MPU6050 gyro / accelerometer
- ATmega328P with Arduino bootloader ( minimOSD )
- MAX7456 on-screen display ( minimOSD )
- FTDI cable compatible pinout ( minimOSD )
- Input voltage 7V to 42V
- PCB maximum continuous current: 120A
- Filtered voltage output: 5.2V 2A
Specification
General |
Brand: Holybro
Type: Main Board |
|---|---|
Dimension and Weight |
Product weight: 0.040 kg
Package weight: 0.080 kg Product size (L x W x H): 0.69 x 0.69 x 0.20 cm / 0.27 x 0.27 x 0.08 inches Package size (L x W x H): 5.00 x 5.00 x 2.00 cm / 1.97 x 1.97 x 0.79 inches |
Package Contents |
Package Contents: 1 x Main Board |
