T150 is a new design multi-functional high power balance charger by HTRC,Utilizing 3.2 inch color LCD Toch screen display,easy operation, built-in cooling fan,DC 11-18V or AC 100-240V dual power.Max charger power 150w,Max charge current 10A.Designed for charging LiPo LiFe Lilon LiHV NiCd NiMh Pb Smart Batteries.
Besides it has a 5V 2.1A USB DC output port, which can be a power supply to other electronic products.
Features:
*Compact touch screen charger, easy to carry, easy to use.
*Practical for variety of batteries.
*Automatic identification of Li-Po batteries cells counts
*Built in cool fan for easy heat dissipation
*Graph display of charging status
*Multiple charging modes.
-Lipo/Lilo/LiFe/LiHv: balance charge, charge, storage, discharge.
-NiMH/NiCd: Charge, Discharge, Cycle.
-PB: Charge,Discharge,Trickle.
-Battery Meter:Display lithium battery cell counts,battery capacity percentage,each cell's voltage. (does not support 1s battery)
-TVC(Terminal voltage control):The Charger allows user to set the charge/discharge end voltage.
-Lithium Battery internal Resistance Check: can display each cell's resistance.(does not support 1s battery)
-Calibration: cell voltage monitoring and calibration. (caliration function for 6s battery only)
-Smart battery:Smart battery I,II,III,and Digital DC Power.(Need optional DJI Charging cable)
*5V 2.1A USB port.
*Data storage and loading
*Battery break in and cyclin
*Built-In PFC
*Firmware update.
*Maximum Safety:Automatic charge current limit,Peak sensitivity, capacity limit, processing time limit,temperature threshold.
Specification:
Model No:HT-0100
Input: AC 100-240V / DC 11-18V
Charge power:Max 150W
Discharge power:10W
Charge current range:0.1-10A
Discharge current range:0.1-2A
Lilon/LiPo/LiFe/LiHV cell count :1-6cells
NiCd/NiMH battery cell count:1-15cells
PB Battery voltage:2-20V
Smart battery:I/II/III
Current drain for balancing: 500mA/cell
Net Weight:0.48kg
Dimension:145*105*64mm
Gross weight:0.80kg
Package size:215*155*75mm
Package Included:
1x T150 charger
1x Charge cable banana plug to T-Plug
1x Extension charge cable T-Plug to XT60
1x balance board with pin cord
1x AC Cord (US EU UK AU optional)
1x DC Cord
1x User's Manual
