Specification:
Brand Name: iFlight
Model: D10
Item Name: 10 Inch 3K Carbon Fiber Macro FPV Frame Kit
Wheelbase: 472mm
Material: 3K Carbon Fiber
Front Arm Distance: 417mm
Back Arm Distance: 369mm
Front Back Arm Distance: 261mm
Inner Standoff Height: 30mm
Arm Thickness: 8mm
Side Plate Thickness: 2mm
Other Plate Thickness: 3mm
Motor Installing Distance: 16-19mm
Net Weight: 346.2mm
Recommend Parts:
Flight Controller: 30.5x30.5mm F3 / F4/ F7 Flight Controller
Motor: 2814 Motor etc.
ESC: 20A-30A ESC
FPV Camera: 28mm Width Camera
Battery: 4S 1550mAh~2200mA
The following parts are compatible: ( Not Included)
FC & ESC Stack: DYS 30.5x30.5mm Stack F4 Pro FC & F30A 4in1 BL_S ESC
Motor & Propeller: EMAX MT-2216 KV810 Brushless Motor With 1045 Propeller
Lipo Battery: TATTU 14.8V 2000mAh 120C 4S Lipo Battery XT60 Plug
Package Included:
1 x 3mm Top Plate
2 x 3mm Mid Plate
4 x 8mm Arm Plate
16 x M3x8mm Steel Screw
10 x M3x14mm Steel Screw
8 x M3 Steel Locknut
8 x M3 Aluminum Locknut
8 x 30mm Aluminum Standoff
