Specification:
Brand Name: iFlight
Model: iPeaka 35A
Item Name: 35A BLheli_S 3-6S 4in1 Brushless ESC
BB21 MCU, 48Mhz Runs BLHELI_S J_H_xx firmware
Constant Current: 35A
Burst Current: 50Amps
Input Voltage: Supports 3-6S Lipo
BEC: 5V 1.5A /12V 2A
Onboard Current Sensor: 180A
BEC: 5V 1.5A /12V 2A
Onboard Current Sensor: 180A
Dimension:42x40x7mm,
Mounting dimensions: 30.5x30.5mm
- 4PWM input
- Current and Voltage output
- Supports oneshot / Multishot / Dshot PWM
- Supports damped light
- PCB - 4 Layer Blind Pole PCB - 3oz Pour
- Mosfet: N-Channel
- Weight: 15.5g
Features:
Features:
- New BusyBee2 MCU at 48MHz, up to 500k eRPM support
- Improved firmware using BLHeli_S
- Hardware PWM driver at 36KHz
- Onboard Current Sensor Range: 0-150A
- Supports DSHOT, Oneshot125 (125-250us), Oneshot42(41.7-83.3us) and Multishot (5-25us). Auto-detection.
- Lightweight, and compact size
- Adaptive timing, compatible with a wide range of motors and Kv
- Synchronous rectification technology adds efficiency, damped light
- Powerful regenerative braking / active braking.
- Highly efficient 5V/1.2A and 12V/2A BEC output.
Notice:
With all ESC's that have active braking we recommend you isolate or filter all sensitive electronics to prevent feedback / spikes.
Package Included:
1x iFlight iPeaka 35A 4in1 ESC
1x Signal Cable for ESC
Notice:
With all ESC's that have active braking we recommend you isolate or filter all sensitive electronics to prevent feedback / spikes.
Package Included:
1x iFlight iPeaka 35A 4in1 ESC
1x Signal Cable for ESC
