iFlight SucceX F7 TwinG Mini-W F7 Flight Controller & 40A 2-6S BL_32 ESC & 48CH 500mW VTX Stack for RC Drone - 90.00 €

Seller: Banggood,
Ship from: CN Warehouse, Usually dispatched in 1-3 work days.

FREE SHIPPING: 10-35 days. (DHL faster please check price/quantity first)

Free shipping aviable, Registered postage from 25 €

iFlight SucceX F7 TwinG Mini-W F7 Flight Controller & 40A 2-6S BL_32 ESC & 48CH 500mW VTX Stack for RC Drone

Specification:
Brand Name: iFlight
Model: SucceX F7 TwinG
Item Name: F7 Flight Controller & 40A 2-6S BL_32 ESC & 48CH 500mW VTX Stack

Mini-W F7 Flight Controller

MCU:168MHz STM32F405

Gyroscope: TwinG ICM20689

Blackbox: 32MB

Betaflight OSD: YES

BEC: 5V 2.5A

Uarts: 4

ESC Telemetry: RX6

-INA Pad: nuart2

Input voltage: 2-6S

CLI dump file: IFLIGHTF4_TWIN_G.config

Size: 27x27mm
Mouting Hole: 20x20mm( M4)

SucceX Mini-W 40A SPECS:

- MCU: STM32F051K66

- Current Sensor: Yes

- Input: 2-6S lipo

- Telemetry: Yes

- Installing Hole: 20x20mm, M4

- Target: iFlight-BL32-4IN1

- BLHeliSuite download

- Constant: 40Amps

- Burst: 45Amps

- Weight:16.7g

Dimensions: 31*31mm(including the power pads)

- Mounting Holes: 20*20mm

- Supports Dshot1200,Proshot,Oneshot,Multishot

5.8G VTX

-Input voltage: 2-6S

-48 standard channels, A/B/E/F/R Band

-Output Power: pit/20/100/200/500mW

-BEC Output: 5V for Camera or FC

-RF Connector: MMCX

-Video Format: NTSC/PAL

Size: 26*26mm /20*20mm φ4 mounting

Package Included:

1x SucceX Mini-W F7 TwinG FC

1x SucceX Mini-W 40A BLHeli_32 ESC

1x5.8G 500mW VTX
