BeeStorm F3 flight control board is highly integrated control with 4 brushed ESCs, flight control, OSD and compatible receiver.
The firmware of BeeStorm is Betaflight. The hardware of its compatible includes 3 version: A---CYRF6936, B---CC2500, C---A7105. The protocols of the compatible receivers: FrSky-D8
Description:
Item Name:Inductrix F3 EVO Brushed Flight Control Board
Usage :DIY Spare Part for Eachine E010 E010S QX65
Features:
- STM32F303CCT6 main controller;
- MPU6500 sensor (SPI way);
- Built-in OSD (BetaFlight OSD);
- Options for compatible receivers (FRSKY-D8)
- On-board boost circuit 5V/500mA DCDC
- 4 brushed ESC, Max current is 3A;
- On-board BOOT switch;
Binding operation:
Long press the binding switch 2 seconds entering binding mode.
Package Included:
1 x Inductrix F3 EVO Brushed Flight Control Board
