Specification:
Brand Name: LD POWER
Model: 2814
510KV motor:
510KV motor:
KV: 510KV
Voltage: 11.1-14.8v
Stator size: 28*14mm
Max sustained current: 30A
Motor size: 35*34mm/52mm(overall length with shaft)
Max power: 444w
Wire length: 110±5mm
N/P: 12N/14P
Top mouting hole: 12,3*M2
Shaft diameter: 4mm
Bottom mouting hole: 19-25/4*M3
No load current: 0.78A
Weight: 105g
880KV motor:
880KV motor:
KV: 880KV
Voltage: 11.1-14.8v
Stator size: 28*14mm
Max sustained current: 52A
Motor size: 35*34mm/52mm(overall length with shaft)
Max power: 754.8w
Wire length: 110±5mm
N/P: 12N/14P
Top mouting hole: 12,3*M2
Shaft diameter: 4mm
Bottom mouting hole: 19-25/4*M3
No load current: 1.37A
Weight: 105g
Package included:
1 x LD POWER FA2814 510KV/880KV CW/CCW Brushless Motor for RC Airplane Fixed Wing
Package included:
1 x LD POWER FA2814 510KV/880KV CW/CCW Brushless Motor for RC Airplane Fixed Wing
