Description:
Makerfire Armor 67 67mm micro FPV racing drone is an incredible brushless palm-sized racer with F3 flight controller, 1103 10000KV high RPM motor and 4-in-1 BLHeli - S 10A ESC for flying at a furious speed. The integrated carbon fiber frame serves as an excellent protection for everything inside, effectively ensuring the durability of the drone. Therefore, it is resistant to considerable impact from the outside, giving you a more carefree flight.
Main Features:
â Powerful and stable - 1103 10000KV brushless motor, and 1535 four-blade propellers
â High-performance F3 flight controller with BetaFlight OSD, 4-in-1 BLHeli - S 10A ESC
â Integration of 600TVL camera, 5.8G 48CH 25mW VTX, and 3dBi whip antenna
â Impact-resistant 3K full carbon fiber frame protects the propellers, motors and so on
â 400mAh 7.4V 2S 30C LiPo battery provides you with about 5 minutes' flying
Specifications:
Wheelbase: 67mm
Flight controller: BetaFlight F3 6DOF with OSD
Flight controller firmware: BetaFlight OMNIBUS
Brushless motor: 1103 10000KV
Brushless ESC: 4-in-1 BLHeli - S 10A
Propeller: 1535 four-blade
Camera: 1/4 inch CMOS 600TVL
Field of view: 120 degree
TV system: NSTC / PAL / AUTO
Video transmitter: 5.8G 48CH 25mW
Battery: 400mAh 7.4V 2S 30C LiPo
Weight: 63g ( with battery ), 41.3g ( without battery )
Click here to download the frequency table.
Specification
General |
Brand: Makerfire
Type: Frame Kit Version: BNF |
|---|---|
Motor |
Model: 1103
Motor Type: Brushless Motor KV: 10000 |
Flight Controller |
Flight Controller Type: F3 |
Camera |
Video Resolution: 600TVL
Sensor: CMOS |
Electronic Speed Controller |
Firmware: BLHeli-S
Functions: DShot300,DShot600,Oneshot125 |
Battery |
Battery (mAh): 400mAh
Battery Coulomb: 30C Flying Time: about 5mins Charging Time.: 25mins |
Dimension and Weight |
Product weight: 0.0630 kg
Package weight: 0.2830 kg Product size (L x W x H): 9.40 x 9.40 x 3.60 cm / 3.7 x 3.7 x 1.42 inches Package size (L x W x H): 16.40 x 11.40 x 5.80 cm / 6.46 x 4.49 x 2.28 inches |
Package Contents |
Package Contents: 1 x Drone ( Battery Included ), 1 x Set of Spare Propellers, 1 x USB Cable, 1 x Battery Strap |
