Mayatech 700TVL 2.8mm FOV 100 Degree Mini FPV Camera DC12V For QAV210 250 FPV Racing Drone RC Aircraft
Description
Lens : 2.8mm
FOV: 100 degree
Size : 25mm*25mm*27.5mm
Weight : 11g
Pixels: PAL: 1020H×596V (61MP) NTSC: 1020H×508V (52MP)
Effective Pixels: PAL: 976H×582V (57MP) NTSC: 976H×494V (48MP)
Resolution(horizontal): 700TVL
Video output amplitude : 1.0Vp-p/75Ω
Auto Gain Control : 0.25/0.50/0.75/1.00 4 levels adjustable, max can be up to 55dB
White Balance : ON/OFF
Exposure mode : electronic exposure
Electronics Shutter : 1/50(1/60) - 1/100000 ç§
Gamma Correct: 0.45/1.0
Synchronization Method: inter-sync
Workong Voltage : DC12V (wide range ,support 7V-13.5V.)
Wording Current : 70mA (low power consumption )
Operating Temp: -20â--60â
Humidity: 0%~ 98%
Cables
Black : -
Red : +
Yellow : Signal
Connector : JST-PH 2.0mm
Note : The back plate has been improved to become thicker
Package Included
1 x Mayatech 700TVL 2.8mm FOV 100 Degree Mini FPV Camera
1 x JST-PH 2.0mm to TJC8 AV Cable
1 x Bracket
1 x Lens Mount
