Micro VTX-OSD 40CH 5.8G 25mw-200mw Mini FPV Transmitter RHCP Integraded OSD For F3
Description : User Manual
Item Name : VTX-OSD
Channles : 40
Frequency Range: 5645-5945mhz
Frequency Range: 5645-5945mhz
Fully Adjustable Power : 25mW - 200mW (default 25mW)
PID Tuning Capable
Built In Battery Status Monitoring
Integrated Flight Timer System
VTx Channel Configurable via the OSD
Connector type: UFL
Piko fc NOT included
Mounting Hole Distance : 20mm x 20mm
Weight: 5g
Features :
Raceband Ready Frequency Layout
Adjustable power 25mW-200mW
Integraded MWOSD Function
Can use remote control transmitter and OSD to adjust its FPV power and channel
Can use remote control transmitter to adjust the PID.
Specifically Designed for the F3
Suitable for 110-115 Micro Racer
Package Included :
1 x VTX-OSD Integraded 40CH 5.8G 25mW - 200mW VTX OSD
1 x RHCP Antenna
2 x UFL to SMA Female Cable
1 x 5P Board
2 x Screw Set
