Note:
LED Version without camera.
Specifications:
Brand Name: Mirarobot
Item NO.: S60
Material: ABS/PS,PP
Motor: Hollow-cup 615
Quadcopter Battery: 3.7V 200mah Lipo Battery (Included)
Remote Control Battery: AA*3 (NOT Included)
Flight Time: 5mins
Charging Time: 30mins
Maximum Tilt Angle: 30°
Operating Frequency: 2405MHZ-2475MHZ
Max Transmitter Power: 4.5dBm
Control Distance: 120m
Transmitter Mode: Mode 2 (Left Throttle Hand)
Quadcopter Size: 90x75x30mm
Weight(Battery included): 27g
Package Size (L x W x H): 25.00 x 19.50 x 7.60 cm
Package Weight: 470g
Camera: (FPV Version)
Product Name: CM275T (25mw)
Modulation: FM
Channels: 48
Maximum signal Distance: 150m
Lens H: 120°
V: 100°
Image resolution PAL: 720*540
NTSC: 640*480
Camera Standard: NTSC/PAL
Operating Frequency: 5645-5945MHz
Frequency Control: PLL
Frequency Stability: +/- 100KHz(Typ.)
Frequency Accuracy: +/- 200KHz(Typ.)
Transmitter Power: 14+/-1dBm
Antenna Port: 50Ω
Power Dissipation: 200-215mA@5V
Operating Voltage: 2.9V-5.5V
Highest Harmonic: -50dBm
Size: 14.5*12*9.22mm
Weight: 4.1g
Features:
- It can be switch 3-a-xis and 6-a-xis control modes (3-a-xis - Angle Self-stabilizing flight mode, 6-a-xis - Semi-stable flight mode), and 3-a-xis Mode is suitable for professional traversing fans. The 6-a-xis Mode is suitable for the novice user.
- The new generation of 2.4GHz two-way remote controller has a great improvement in accuracy and distance, maximum distance reaches 120m.
- Low voltage alarm feel at ease while flying.
- If the receiver does not receive the signal for 2sec, it will gradually reduce the throttle value until 1080.
- The remote control support low-voltage prompt.(Transmitter beeps under 2.9V. Return to Low-voltage condition over 2.95V.)
Package Included:
1 x S60 FPV Racing Quadcopter
1 x Remote Control
1 x 3.7V 200mAh Lipo Battery
4 x Propeller
1 x USB Charging Cable
1 x User Manual
