Highlights
- Based on BLHeli firmware, ptimized for perfect drive performance
- Low-voltage protection, over-heat protection and throttle signal loss protection
- Separate power supply for MCU and BEC, enhancing the ESC’s ability to eliminate magnetic interference
- Parameters of the ESC can be set via program card or transmitter
- Throttle range can be set to be compatible with various receivers
- Equipped with linear BEC or switch BEC
- Low CG design
- Light weight design
- Longer duration of flight
- For QAV250 FPV 250 mini multirotor
- Come with one pair of propellers, fits for 250mm fram kit
Specification
General | |
---|---|
Type | Frame Kit Combo |
Max Speed | 210,000 rpm for 2-pole, 70,000 rpm for 6-pole, 35,000 rpm for 12-pole |
Current | 12A |
Compatible | QAV250 FPV 250 mini multirotor |
Motor | KV 2300 No. of Cell 2S -3S Framework 4P12N1 Propeller: 5 - 6 inch Shaft diameter: 3mm Diamter: 27.9mm Length: 32.2mm Weight 25g |
Package Contents | |
4 * Motor | |
4 * Propeller | |
4 * Motor accessory | |
4 * ESC | |
1 * Frame kit |
