Description:
BeeStorm F4 is a highly integrated brushed flight control board, it includes 4 brushed ESCs, a flight control, a OSD and a compatible receiver.
Flight control uses BetaFlight firmware. The onboard compatible receiver is as reliable and fast response as the original made after tuning the program.
Specifications:
Brand Name: Oversky
CPU: STM32F411CEU6
Six-Axis: MPU6500 sensor (SPI)
OSD: Built-in BetaFlight OSD
Weight:3.25g
Size:29*29*7mm
Power cable length:5cm
Connector: 1.25mm 2P
Bulit-in Receiver Option: Frsky 8CH protocol D16 Mode
Fu-taba SFHSS protocol
Features:
- It compatible 5 kinds of protocol: A1-> DSMX/2; B1-> Fu-taba SFHSS; B3-> FrSky-D16; C1-> FS AFHDS; C2-> FS AFHDS-2A ; Hubsan
- Those supports Telem function: A1-> DSMX/2; B3-> FrSky-D16; C2→AFHDS-2A
- The hardware of compatible receivers includes 3 types: A---CYRF6936, B---CC2500, C---A7105;
- Supports RSSI output (SBUS and F PORT output signal is on 14CH)
- Onboard 5V/500mA DCDC boost circuit;
- Onboard 4 brushed ESCS (Supports up to 3A);
- Onboard BOOT switch;
Binding operation:
1. There are two kinds of binding way: one way is long press (2 seconds) the binding button on the powered board, the FC will enter binding mode; The second way is timeout entering binding mode automatically.
2. Long press binding way receivers: B1-> Fu-taba SFHSS; B3-> FrSky-D16;
3. Timeout binding way receivers: A1-> DSMX/2; C1-> FlySky AFHDS; C2-> FlySky AFHDS-2A ;
Note: Fast flashing red LED indicates binding mode, solid bright red LED means binding succeed and done, the receiver is getting stable signal.
Package Included:
1 x Flight Controller
