Racerstar Racing Edition 2205S BR2205S 2600KV 2-4S Brushless Motor CW/CCW For X210 220 QAV250 280 FPV Racing Frame
Description:
Brand: Racerstar
Item name: BR2205S 2600KV Brushless Motor
RPM/V: 2600KV
Height: 33mm
Width: 27.9mm
Shaft diameter: M5
Motor mount hole size: M3
Weight: 29 grams
Voltage: 2-4S
Battery: 2-4S lipo battery
Internal resistance: â¦
Usage: X210 220 QAV250 280 FPV Racing Frame
Tested with 14.8V voltage 4045 propellers:
Load current: 23.2A
Pull: 710g
Power: 343W
Efficiency: 2.1 (g/W)
CW screw thread motor comes with red cap
CCW screw thread motor comes with black cap
Features:
Long life Japanese NMB ball bearings
Efficient Japanese Kawasaki stator steel
N40SH magnetic steel stable up to 180°
Oxygen free copper wire
7075-T10 7050 aviation aluminum-alloy material
CNC machined aluminum case
Silicone wire leads
Patented balance techniques
Unique wiring method
Upgrade propeller base
Anti-skidding screw thread to prevent propellers from skidding.
5mm stainless hollow shaft
Imported NMB high end mute bearing
99.99% Oxygen free copper wire, high effciency assurance.
Prevent falling technology
Integrated stainless steel shaft
CNC processing technic
Factory 100% dynamic balancing treatment
Package included:
1 x BR2205S 2600KV Brushless Motor
