Realacc X210 4mm Frame + F3 6 DOF + 4X Racerstar BR2205 2300KV Motor + 4X RS20A V2 Blheli_S ESC + 7 Pairs Kingkong 5X4X3 Prop
Items Specifications Features Realacc X210 FPV Racing Frame
Wheelbase: 214mm
Material: carbon fiber
Weight:
3mm frame arm version: 72g (frame + hardware), 77g (with battery protector plate)
4mm frame arm version: 88g (frame + hardware), 93g (with battery protector plate)
Full 3K Carbon Fiber frame.
4mm frame arms.
Dual purpose FPV and HD camera mounting solution.
Compact size for 5" propellers, 214mm motor to motor.
Multiple motor mounting holes to fit a variety of motors (M3 and M2 screw mounting patterns).
"Bumpers" on the end of the arms to protect the motor during a crash, just like the QAV250.
Included power distribution board and XT-60 Pig-Tail to power ESCs and FPV flight electronics.
LiPo battery protection plate included.
Support to carry HD camera at 35 degree angle(such as the GoPro 4, Mobius, etc).
Lightweight and rigid
F3 Flight Control Acro 6DOF
35x35mm board, 30mm mounting holes.
STM32F3 CPU.
High-capacity Flash
MPU6050 Accelerometers and Gyroscopes
MicroUSB socket.
4 x 4 pin JST-SH Socket (I2C, SWD, 2xuart)
2 x 8 pin JST-SH Socket (PPM, PWM, SERIAL RX, GPIO, ADC, 3V, 5V, GND)
8 x 3 pin though-holes for pin headers for ESC / Servo connections.
2 x 4 pin though-holes for the 2x serial ports .
2 x 2 pin though-holes for battery voltage and buzzer.
Racerstar Racing Edition BR2205 2300KV 2-4S Brushless Motor
RPM/V: 2300KV
Height: 31.5mm
Width: 27.9mm
Shaft diameter: M5
Motor mount hole size: M3
Weight: 28 grams
Voltage: 2-4S
Battery: 2-4S lipo battery
Max.current: 27.6A
Max.power: 408W
Internal resistance: â¦
Usage: for 250 260 280 Multirotor Frame Kit
CW screw thread motor comes with red cap
CCW screw thread motor comes with black cap
Racerstar RS20A V2 20A Blheli_S BB2 48MHZ OPTO 2-4S ESC
Con.Current:20APeak Current(10s):25A
Input Voltage: 2-4S
BEC: No
Programming : YES
Firmware: Blheli_S
Net Weight: 5.67g
Size:27*12mm
Chips on EFM8BB21F16, 48MHZ Greatest .
BLHeli_S is designed for superior performance in multirotors, and uses hardware generated motor pwm for smooth throttle response and silent operation.
Small size combined with light weight for easy installation.
The code supports regular 1-2ms pulse width input, as well as Oneshot125 (125-250us), Oneshot42 (41.7-83.3us) and Multishot (5-25us).
The input signal is automatically detected by the ESC upon power up.
All codes use damped light mode.Damped light does regenerative braking, causing very fast motor retardation, and inherently also does active freewheeling
The code supports features to prevent sync loss. There are tuneable parameters that can make the code run well even in the most demanding situations, although default settings will work
excellently in normal operating environments
The code also supports a beacon functionality, where the ESC will start beeping after a given time of zero throttle. This can be very useful for finding lost crafts.
7 Pairs Kingkong 5X4X3 5040 5 Inch 3-Blade Rainbow Colorful Propeller
Color: Red, Orange, YelloW, Green, Pink, Purple and Black
Quantity: 7 Pairs (One Pair Each Color)
Mounting Hole: 5mm
Weight: 119g
Size: 140*140*65 mm
Package included:
1 x Realacc X210 carbon fiber frame kit
1 x Matek PDB-XT60 5V & 12V
1 x F3 Flight Control
2 x 8p Wire Rod
2 x 4p Extension Path
5 x Pins set
2 x BR2205 2300KV Brushless Motor CW
2 x BR2205 2300KV Brushless Motor CCW1 x F3 Flight Control
2 x 8p Wire Rod
2 x 4p Extension Path
5 x Pins set
2 x BR2205 2300KV Brushless Motor CW
4 x Racerstar RS20A V2 20A ESC
7 x 5040 CW Propellers
7 x 5040 CCW Propellers
