Defference Between LINK & AIR UNIT version:
1. Air Unit comes with 2 antenna for better transmission
2. Air Unit support DVR recording, Link kit doesn't.
Features
8 CHANNELS for DRONES
The HDL FPV Transmission system and the FPV Air Unit are equipped with eight frequency channels, which allow up to eight drones to
fly simultaneously. Each operator has an exclusive channel. This helps to reduce cross-interference and provide an optimal racing experience.
Embedded Remote Controller Receiver
Users can wirelessly connect their DJI FPV Air Unit to the DJI FPV Remote Controller without having to purchase additional receivers. This reduces flight preparation time significantly.
RUNCAM Phoenix HD Camera
Use 1/2 inch, up to 10650 mV/Lux-sec ultra-high sensitivity sensor, excellent night vision effect.
At 1280 x 720 60fps resolution
the delay is as low as 32ms, which is suitable for freestyle flying.
Air Unit Supports 720P 60fps DVR Recording
Parameters
Model | RunCam LINK Phoenix HD Kit |
Frequency | 5.725-5.850 GHz |
Max. Distance | FCC/SRRC: <4 km & CE: <0.7 km |
Power | 7.4-26.4 V@ 4-9W |
Dimensions | 29Ã29Ã13 mm |
Net Weight | 19.5 g |
Model | RunCam Phoenix HD |
Image Sensor | 1/2â |
Resolution | 1280*720@60fps |
LENS | FOV D:157° H:133° V:72° |
Shutter | Rolling Shutter |
Coaxial Cable | 120 mm |
Dimensions | L19mm*W19mm*H23.5mm |
Net Weight | 7.5g |
User Manual
RunCam Link Phoenix HD Kit Manual
Air Unit Phoenix HD Kit Manual
Packing listï¼ Optional
1 x Camera
or
1 x Camera
1 x VTX
1 x Antenna
1 x Cable Wire
