RunCam Micro Swift:
to download the manual: Manual.pdf
Specification:
Model: RunCam Miâcro Swift
Image Sensor: 1/3" SONY Super HAD II CCD
Horizontal Resolution: 600TVL
Lens: 2.1mmâ Lens(M8)â â
FOV: 160 degree(2.1mm) / 145 degree(2.3mm)
Signal System: PAL / NTSC
S/N Ratio: >60dB(AGC OFF)
Electronic Shutter Speed: PAL:1/50 ~ 100,000; NTSC:1/60 ~ 100,000
AutoGain Control(AGC): YES
Back light compensation(BLC): YES
Min.illumination: 0.01Lux/1.2F
WDR: D-WDR
DNR: 2DNR
Day/Night: Color / Auto / B&W
Power: DC 5 to 36V
Net weight: 5.â6g
Dimensions: 19mm * 19mm * 19mm
Runcam TX25:
to download the manual: Manual.pdf
Description:
Brand name:Runcam
Frequency Channel: 5.8G 6 Band 48CH
Output Power: 13dBm / 25mW
Voltage in: 1S 3.5-5.5V
Working Current: 5V@ 150mA
Voltage out: 4.5V@max 250mA
Video Input Impedance: 75 Ohm
Antenna : 5.8G 2dB Omni antenna
PCB Size: 19mm*19mm
Weight: 2.5g (with antenna)
Feature:
It is suitable for Runcam Micro Swift Micro Swift 2.
Package included:
1 X Camera
1 X 1.25mm 3pin to 1.25mm 3pin FPV silicone cable
1 X 1.25mm 3pin to 1.0mm 3pin FPV silicone cable
1 x RunCam TX25 Video Transmitter1 x Set of screws
